Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has established itself as a trusted name for top-tier metal solutions, with a special focus on the exceptional Zirconium Bar and Rod. We are proud to supply industries with materials that are not only robust but also purpose-built to excel in the most demanding environments, serving as a cornerstone for innovation and reliability in the region.
What truly sets our Zirconium Bar and Rod apart is their remarkable composition, which grants them superior corrosion resistance, especially against acids and alkalis. This is paired with impressive mechanical strength and a unique resistance to high heat. It’s this combination that makes our zirconium products a dependable choice where other metals might fail, ensuring longevity and performance under pressure.
| Standards : | ASTM B493 |
| Size : | 5.0mm diameter x L |
| Specification : | ASTM B550/550M-07 |
| Length : | 2m, 2.44m, 3m, or as required |
| Surface : | Turning, Grinding |
| Grade | Zr+Hf | Hf | Fe+Cr | Sn | H | N | C | O | Nb |
| R60702 | 99.2% | <4.5% | <0.20% | – | <0.005% | <0.015% | <0.030% | <0.15% | – |
| R60704 | 97.5% | <4.5% | 0.2-0.4% | 1.0-2.0% | <0.005% | <0.015% | <0.030% | <0.16% | – |
| R60705 | 95.5% | <4.5% | <0.2% | – | <0.005% | <0.015% | <0.050% | <0.16% | 2.0-3.0% |
| Molecular Weight | 91.22 |
|---|---|
| Appearance | White |
| Melting Point | 1852 °C |
| Boiling Point | 3580 °C |
| Density | 6506 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 40.0 microhm-cm @ 20 oC °C |
| Electronegativity | 1.4 Paulings |
| Heat of Fusion | 5.50 Cal/gm mole |
| Heat of Vaporization | 120 K-Cal/gm atom at 4377 °C |
| Poisson’s Ratio | 0.34 |
| Specific Heat | 0.0671 Cal/g/K @ 25 oC °C |
| Tensile Strength | 230 MPa |
| Thermal Conductivity | 0.227 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 5.7 µm·m-1·K-1 |
| Vickers Hardness | 903 MPa |
| Young’s Modulus | 88 GPa |
Yes, Zirconium bars can be welded. It requires specialized techniques such as gas tungsten arc welding (GTAW) to ensure good weld quality, as it is highly reactive at elevated temperatures.
To maintain zirconium rods, keep them clean and free of contaminants. Store in a dry, cool environment. Avoid mechanical damage and ensure proper handling to prevent oxidation or corrosion.
Zirconium bars are generally resistant to galvanic corrosion due to their high corrosion resistance properties. However, when paired with more reactive metals, galvanic corrosion may still occur.
Because of these properties, you’ll often find our Zirconium Bar and Rod hard at work in critical chemical processing plants, powerful pumps, and advanced heat exchangers. They are also indispensable in demanding fields like medical technology for surgical instruments and within the aerospace industry, proving that true strength lies in providing versatile, reliable solutions that power progress across countless sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
