For over [Number] years, Nimish Metal in Safat has been a trusted name for industrial materials, built on a foundation of reliability and expert service. We take particular pride in our specialized supply of Titanium Grade 7 forgings, a material chosen for its exceptional performance in the most demanding environments. Our team understands that your projects require components you can count on, which is why we ensure our Grade 7 forgings meet the highest standards of quality and integrity, providing you with a durable and dependable solution right here in Kuwait.
Titanium Grade 7 is distinguished by its specific composition, which includes the addition of palladium to a commercially pure titanium base. This small but crucial addition significantly enhances its corrosion resistance, particularly against reducing acids. The resulting mechanical properties offer an excellent balance, providing high strength comparable to other titanium grades while maintaining good ductility and formability. This unique combination makes it exceptionally tough and reliable for critical components where failure is not an option.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Yes, Titanium Grade 7 (Ti-0.2Pd) is highly corrosion-resistant, especially in harsh environments like seawater and acidic conditions, due to the addition of palladium, enhancing its ability to resist corrosion.
Titanium Grade 7 forgings are commonly used in industries like aerospace, chemical processing, marine, medical, and power generation due to their exceptional corrosion resistance, strength, and biocompatibility in challenging environments.
Titanium Grade 7 forgings are available in various sizes and shapes, including bars, billets, rings, discs, and custom configurations, typically ranging from small to large diameters for different industrial applications.
The superior corrosion resistance of Titanium Grade 7 forgings makes them indispensable across several demanding industries. They are commonly used in chemical processing equipment for handling acids, in pollution control scrubbers, and within demanding hydrometallurgical applications. You will also find these forgings in critical components for marine and offshore structures, as well as in pharmaceutical and food processing plants where purity and resistance to aggressive media are paramount. Essentially, wherever extreme conditions threaten material integrity, Grade 7 provides a robust and long-lasting solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
