Nestled in the industrial heart of Safat, Kuwait, Nimish Metal stands as a trusted name for high-performance metal components. We specialize in providing superior Titanium Grade 1 Forgings, known for their exceptional formability and corrosion resistance. Our commitment is to deliver components that set the standard for quality and reliability. For projects where purity and performance are non-negotiable, Nimish Metal is your dedicated partner, ensuring you receive precision-forged solutions that truly make a difference.
When it comes to composition, Titanium Grade 1 is the purest form of commercially available titanium, which is the secret to its incredible softness and ductility. Mechanically, this translates to superior cold-forming properties, making it a dream to work with for complex shapes. While it offers the lowest strength among titanium grades, it more than compensates with champion-level corrosion resistance, especially against chlorides, and excellent impact toughness even in challenging environments.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | O | N | Fe | H | Ti | I |
| Min | – | – | – | – | – | 99.095 | – |
| max | 0.080 | 0.18 | 0.030 | 0.2 | 0.015 | 100 | 0.2 |
| Grades | Tensile KSI Min | Yield KSI Min/Max | % Elongation Min |
| Titanium Gr 1 | 35 | 25/45 | 24 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 1 | 3.7025 | R50250 |
Titanium Grade 1 forgings are commonly used in aerospace, chemical processing, marine, medical, and automotive industries due to their excellent corrosion resistance, lightweight, high strength, and biocompatibility properties.
Titanium Grade 1 forgings are made by heating titanium billets, then shaping them using compressive forces like hammering or pressing, followed by precision machining to achieve the desired specifications.
Open-die forging for Titanium Gr 1 involves compressing heated titanium between flat or contoured dies, allowing metal to deform freely, producing strong, customized components with excellent structural integrity.
The superb corrosion resistance and formability of Titanium Grade 1 Forgings make them a natural choice for demanding chemical processing applications, including heat exchangers, pipes, pumps, and valves that handle aggressive media. You will also find them extensively used in the architecture and marine industries for components like cooling wheels, tubing, and fittings. Essentially, wherever extreme corrosion is a primary concern and high strength is not the main goal, these forgings provide a reliable, long-lasting solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
