Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a strong reputation for delivering exceptional metal solutions, with a particular expertise in high-performance alloys. We take pride in supplying top-tier Stainless Steel 904L Forgings, engineered for the most demanding environments. Our commitment is to provide forged components that offer unparalleled corrosion resistance and lasting durability, ensuring your critical projects are supported by material integrity you can trust, backed by our local presence and reliable service.
The strength of Stainless Steel 904L lies in its specialized composition, which includes higher concentrations of chromium, nickel, and molybdenum, along with added copper. This unique blend gives it superior resistance to a wide range of corrosive substances, particularly sulfuric acid. In terms of mechanical performance, these forgings offer an excellent combination of high tensile strength and good impact toughness, even in challenging conditions. This makes the material exceptionally reliable for heavy-duty use where failure is not an option.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | Cu | |
| 904L | min. | – | – | – | – | – | 19.0 | 4.0-5.0 | 23.0 | 1.0 |
| max. | 0.20 | 2.0 | 1.0 | 0.045 | 0.035 | 23.0 | 28.0 | 2.0 | ||
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Yes, Stainless Steel 904L can be forged into custom shapes. Through advanced forging techniques, it can be shaped into various configurations to meet specific design and performance requirements for different applications.
Stainless Steel 904L forgings require minimal maintenance. Regular cleaning with mild detergents, periodic inspections for corrosion, and avoiding high-temperature exposure to chloride-rich environments ensure optimal performance and longevity.
Yes, Stainless Steel 904L forgings can be customized for specific applications. They can be tailored in size, shape, and finish to meet unique requirements, ensuring optimal performance in various industries.
The exceptional properties of 904L Forgings make them indispensable across several critical industries. They are widely used in chemical processing plants for handling aggressive acids, in pollution control scrubbers, and within sophisticated desalination units. The oil and gas sector relies on them for components that withstand sour environments, while the pharmaceutical and food industries value them for their purity and cleanability. Essentially, wherever extreme corrosion is a primary concern, these forgings provide a robust and dependable solution for long-term operational success.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
