Nestled in the industrial hub of Safat, Kuwait, Nimish Metal has built a solid reputation as a trusted manufacturer and supplier, particularly known for its expertise in high-performance alloys. Our Stainless Steel 317L Square Bars and Rods are a testament to this commitment, designed to meet the most demanding industrial challenges. We understand that the integrity of your projects relies on the quality of materials, which is why we ensure every bar is crafted for superior strength and exceptional corrosion resistance, providing a reliable foundation you can count on.
The composition of Stainless Steel 317L includes elevated levels of chromium, nickel, and molybdenum, along with a low carbon content. This specific blend gives these square bars and rods outstanding resistance to corrosion, even in harsh chemical environments. Mechanically, the material offers excellent toughness and durability. It retains its strength and structural integrity across a wide range of temperatures, making it a robust and dependable choice for critical applications where failure is not an option.
Stainless Steel 317L Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 15.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4438 | S31703 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 317L square bars and rods can be recycled after use. They retain their properties and can be repurposed for new applications, making them highly sustainable.
To ensure the quality of Stainless Steel 317L square rods, source them from reputable suppliers and conduct material tests such as chemical composition and mechanical properties. Additionally, check for compliance with relevant industry standards and certifications.
Yes, Stainless Steel 317L square bars can be used for underground applications due to their excellent corrosion resistance, particularly in environments with high moisture or chloride exposure. Their durability ensures long-lasting performance in such conditions.
These square bars and rods are indispensable in industries where exposure to aggressive chemicals is a daily reality. You will often find them forming the structural framework in chemical processing plants, wastewater treatment facilities, and manufacturing units. They are also the material of choice for constructing pipelines, heat exchangers, and other equipment in coastal or marine settings. Essentially, wherever extreme corrosion is a primary concern, 317L provides the durable, long-lasting performance needed to ensure safety and operational continuity.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
