Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a reputation as a trusted name for high-grade industrial materials. We specialize in providing top-tier Stainless Steel 316l Hex Bar and Rod, supplying various industries with components they can count on. Our commitment is to deliver not just metal, but durable, reliable solutions that stand up to the demanding environments our clients work in every single day.
This particular grade of stainless steel is defined by its excellent composition, which includes a higher chromium, nickel, and molybdenum content. The addition of molybdenum significantly boosts corrosion resistance, especially against chlorides and industrial solvents. Mechanically, it offers a tensile strength of around 485 MPa and a minimum yield strength of 170 MPa, providing a robust foundation for projects where both strength and ductility are critical. This combination makes it exceptionally durable and long-lasting.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 316L Hex Bars/Rods offer exceptional resistance to corrosion, including pitting and crevice corrosion caused by chlorides, due to their chromium and molybdenum content. Their low carbon levels prevent sensitization, ensuring durability in marine and chemical environments.
SS 316L Hex Bars/Rods are used in marine, chemical processing, food, pharmaceutical, and oil and gas industries. Their superior corrosion resistance enhances longevity and performance, particularly in environments exposed to chlorides, acids, alkalis, and high-moisture conditions.
Yes, SS 316L Hex Bars/Rods are easily welded and machined due to their low carbon content. However, precautions include using appropriate tools to avoid work hardening, maintaining low heat input during welding, and employing post-weld cleaning to prevent contamination.
You will typically find Stainless Steel 316l Hex Bar and Rod hard at work in challenging environments. They are ideal for constructing chemical processing equipment, marine components, and pharmaceutical machinery, where resistance to corrosion is non-negotiable. These bars are also essential in architectural applications near the coast, in food and beverage processing plants, and even in surgical instruments. Essentially, wherever strength and exceptional resistance to rust are required, this versatile material is the go-to choice for engineers and builders.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
