Based in Safat, Kuwait, Nimish Metal is a trusted name for high-performance industrial materials, specializing in the supply and manufacture of precision Nickel Alloy 200 forgings. We understand that the integrity of your core components is paramount, which is why our forged products are crafted to deliver exceptional reliability in the most demanding environments. Our commitment is to provide not just a material, but a robust solution that ensures the longevity and efficiency of your critical operations, backed by our local expertise and a dedication to superior quality.
Nickel Alloy 200 is valued for its high nickel content, typically over 99%, which gives it outstanding resistance to corrosion, especially in caustic environments. This non-age-hardenable alloy also offers excellent mechanical properties, including good thermal and electrical conductivity. Forged components exhibit enhanced strength and structural integrity, capable of performing reliably from sub-zero temperatures up to moderately high heat, making them a fundamentally sturdy and dependable choice for critical applications.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | BS 3072, BS 3073, BS 3074, BS 3075, BS 3076, NA11 DIN 17740, 17750, 17751, 17752, 17753, 17754, DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
After forging Nickel Alloy 200, controlled cooling methods such as air cooling or furnace cooling are typically used to avoid rapid temperature changes and prevent distortion. Gradual cooling helps maintain the material's mechanical properties and prevent cracking.
Post-forging operations for Nickel Alloy 200 include annealing to relieve internal stresses and improve ductility, followed by machining or surface finishing to achieve precise dimensions and surface quality. These processes ensure the alloy's optimal performance and structural integrity.
The ideal temperature range for forging Nickel Alloy 200 is between 1,900°F (1,038°C) and 2,100°F (1,149°C). This range ensures proper malleability and helps achieve the desired mechanical properties during the forging process.
The inherent strengths of Nickel Alloy 200 forgings make them indispensable across several key sectors. They are widely used in chemical processing for equipment like vessels, valves, and pumps that handle caustic soda and other aggressive chemicals. The aerospace and electronics industries rely on them for components requiring high conductivity and stability. Furthermore, they are essential in food processing and synthetic fiber production, where their purity and corrosion resistance ensure product integrity and operational safety in demanding thermal and chemical conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
