Nimish Metals, based in Safat, Kuwait, is a leading manufacturer of high-quality metal products for diverse industries. Our Monel Round Bars are forged using Monel alloy a high-performance alloy that has unique strength and corrosion resistance characteristics to withstand the harshest environments. These bars are available in different sizes and grades. Which can be used in aerospace, marine, chemical processing, and oil and gas applications. We manufacture each Monel Round Bar with the specifications to provide reliability and durability across a spectrum of industrial applications.
Basically, it is a cylindrical rod made from Monel Alloy which is a high-performance material known for its outstanding strength, corrosion resistance and performance in very extreme environments. These bars are extensively used in various industries, such as marine, aerospace, chemical processing, drilling, and oil and gas. Monel Round Bars mainly consist of nickel (63%), copper (about 28% to 34%), and tiny amounts of iron, manganese, carbon, and silicon. All these enhance the strength-resistance properties of the alloy, especially in seawater and acidic conditions. These unique properties make Monel especially useful for high-stress, corrosive conditions in such round bars.
| Specifications | : | ASTM B164 / ASTM SB164 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 5 mm To 500 mm |
| Diameter | : | 0.1 mm to 100 mm |
| Length | : | 100 mm To 3000 mm Long & Above |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | : | Round |
| Designation | C% | Co% | Cr% | Mo% | Ni% | V% | W% | Ai% | Cu% | Nb/Cb Ta% | Ti% | Fe% | Sonstige Autres-Other % |
| – | 0.12 | – | – | – | 65.0 | – | – | – | 32.0 | – | – | 1.5 | Mn 1.0 |
| – | 0.10 | – | – | – | 43.0 | – | – | – | 53.0 | – | – | 0.75 | Si 0.25; Mn 2.25 |
| – | 0.15 | – | Â | Â | 52.0-57.0 | – | – | 0.05 | rest/bal | – | – | 0.50 | Mn 0.10; Si 0.10;S o.024 |
| – | 0.10 | – | – | – | 63.0-17.0 | – | – | 2.5-3.5 | rest/bal | – | 0.50 | 2.0 | Mn 1.5;Si 0.5; S 0.010 |
| – | 0.13 | – | – | – | 64.0 | – | – | 2.8 | 30.0 | – | 0.6 | 1.0 | Mn 0.8 |
| – | 0.15 | – | – | – | 66.0 | – | – | – | 31.0 | – | – | 1.2 | Mn 1.0; S 0.04 |
| Element | Monel |
| Density | 8.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 35,000 , MPa – 240 |
| Elongation | 40 % |
| Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot |
|---|---|---|---|---|---|---|---|---|
| 1/8″ | 0.062 | 0.019 | 22 millimeter | 2.979 | 0.908 | 3 to 1/4″ | 41.996 | 12.800 |
| 3 millimeter | 0.055 | 0.017 | 20 millimeter | 2.470 | 0.753 | 3″ | 35.762 | 10.900 |
| 4 millimeter | 0.098 | 0.030 | 24 millimeter | 3.543 | 1.080 | 3 to 3/4″ | 55.780 | 17.001 |
| 5/32″ | 0.095 | 0.029 | 7/8″ | 3.038 | 0.926 | 3 to 1/2″ | 48.772 | 14.850 |
| 5 millimeter | 0.154 | 0.047 | 1″ | 3.970 | 1.210 | 4 to 1/4″ | 72.249 | 21.908 |
| 3/16″ | 0.141 | 0.043 | 25 millimeter | 3.871 | 1.180 | 4″ | 63.340 | 19.306 |
| 6 millimeter | 0.223 | 0.068 | 27 millimeter | 4.490 | 1.368 | 4 to 3/4″ | 90.249 | 27.366 |
| 7/32″ | 0.190 | 0.058 | 26 millimeter | 4.170 | 1.271 | 4 to 1/2″ | 80.340 | 24.4487 |
| 7 millimeter | 0.298 | 0.091 | 30 millimeter | 5.548 | 1.691 | 5 to 1/2″ | 121.000 | 36.690 |
| 1/4″ | 0.249 | 0.076 | 1 to 1/8″ | 5.033 | 1.534 | 5″ | 99.940 | 30.461 |
| 8 millimeter | 0.398 | 0.120 | 32 millimeter | 6.314 | 1.894 | 6 to 1/2″ | 167.630 | 51.093 |
| 5/16″ | 0.387 | 0.118 | 1 to 1/4″ | 6.349 | 1.924 | 6″ | 143.900 | 43.860 |
| 3/8″ | 0.557 | 0.170 | 35 millimeter | 7.553 | 2.390 | 7 to 1/2″ | 225.000 | 68.226 |
| 9 millimeter | 0.498 | 0.152 | 1 to 3/8″ | 7.550 | 2.303 | 7″ | 196.000 | 59.432 |
| 11 millimeter | 0.748 | 0.228 | 38 millimeter | 8.903 | 2.792 | 10″ | 397.140 | 121.048 |
| 10 millimeter | 0.620 | 0.189 | 36 millimeter | 7.999 | 2.438 | 8″ | 254.55 | 77.586 |
| 12 millimeter | 0.889 | 0.271 | 40 millimeter | 9.872 | 3.009 | Â | Â | Â |
| 7/16″ | 0.761 | 0.232 | 1 to 1/2″ | 8.951 | 2.715 | Â | Â | Â |
| 13 millimeter | 1.043 | 0.318 | 1 to 3/4″ | 12.179 | 3.712 | Â | Â | Â |
| 1/2″ | 0.994 | 0.303 | 1 to 5/8″ | 10.449 | 3.200 | Â | Â | Â |
| 9/16″ | 1.256 | 0.383 | 1 to 7/8″ | 13.977 | 4.260 | Â | Â | Â |
| 14 millimeter | 1.207 | 0.368 | 45 millimeter | 12.555 | 3.807 | Â | Â | Â |
| 5/8″ | 1.551 | 0.473 | 50 millimeter | 15.414 | 4.698 | Â | Â | Â |
| 15 millimeter | 1.391 | 0.424 | 48 millimeter | 14.205 | 4.330 | Â | Â | Â |
| 17 millimeter | 1.791 | 0.543 | 2 to 1/8″ | 17.963 | 5.475 | Â | Â | Â |
| 16 millimeter | 1.578 | 0.481 | 2″ | 15.906 | 4.848 | Â | Â | Â |
| 18 millimeter | 2.001 | 0.610 | 60 millimeter | 22.205 | 6.768 | Â | Â | Â |
| 11/16″ | 1.880 | 0.573 | 2 to 1/4″ | 20.128 | 6.135 | Â | Â | Â |
| 3/4″ | 2.237 | 0.682 | 2 to 3/8″ | 22.435 | 6.838 | Â | Â | Â |
| Â | Â | Â | 2 to 1/2″ | 24.856 | 7.576 | Â | Â | Â |
| Â | Â | Â | 2 to 5/8″ | 27.409 | 8.354 | Â | Â | Â |
| Â | Â | Â | 2 to 3/4″ | 30.083 | 9.169 | Â | Â | Â |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@nimishmetal.com
Monel Round Bars are widely used in marine, chemical processing, and aerospace industries for components that require excellent corrosion resistance and high strength in extreme environments.
Yes, Monel Round Bars can be heat treated to improve their mechanical properties, such as strength and hardness, making them suitable for high-performance applications.
Â
Monel Round Bars are employed in many industries that require the highest levels of strength and corrosion resistance. In the marine industry, they serve applications such as propeller shafts, pumps and seawater piping due to their resistance to saltwater corrosion. Chemical processing uses Monel Round Bars for valves heat exchangers, and reactors where resistance to acids and alkalis is vital. Engine components and fasteners are built from these materials by the aerospace industry. Monel Round Bars are utilized in the oil and gas industries for durability in offshore platforms and drilling equipment in difficult, high-stress areas.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
