Based in the industrial heart of Safat, Kuwait, Nimish Metal has built a strong reputation as a trusted manufacturer and supplier of high-performance materials. We specialize in providing top-quality Monel K500 forgings, recognized for their exceptional strength and corrosion resistance. Our dedicated team understands the demanding environments our clients operate in, which is why we focus on delivering components that are not just products, but reliable, long-term solutions for critical applications, ensuring our partners can build and operate with absolute confidence.
Monel K500 is a nickel-copper alloy fortified with aluminum and titanium, giving it a significant edge. This unique composition allows it to be age-hardened, resulting in impressive mechanical properties. It offers a high tensile strength and excellent yield strength, all while maintaining good ductility. What truly sets it apart is that it retains the superb corrosion resistance of standard Monel 400, but with the added durability and hardness needed to withstand wear and abrasive conditions, making it a truly versatile material.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel K500 Forging UNS (N05500), DIN (2.4375)
BS3072 NA18, QQ-N-286, DIN 17750, ISO 6208
AMS 4676, BS3076 NA18, ASTM B 865, DIN 17752, QQ-N-286, ISO 9723
AMS 4676, ISO 6208, ASTM B 865, DIN 17752, QQ-N-286
BS3076, NA18, DIN 17753, QQ-N-286, ISO 9724
DIN 17754, QQ-N-286, ISO 9725
UNS N05500, BS6076 NA13, Werkstoff Nr. 2.4375, MIL-N-24549, NACE MR-01-75
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
| STANDARD | UNS | WNR. |
| Monel K500 | N05500 | 2.4375 |
Temperature control during the forging of Monel K500 ensures optimal microstructure, improving strength, toughness, and corrosion resistance. It prevents defects like cracking and ensures consistent quality.
To improve the surface finish of forged Monel K500 parts, use techniques like polishing, grinding, or shot peening. Additionally, applying chemical treatments such as pickling can help remove oxides and enhance smoothness.
To determine if Monel K500 forgings meet your needs, evaluate their mechanical properties, corrosion resistance, and compliance with industry standards.
The exceptional combination of strength and corrosion resistance makes Monel K500 forgings indispensable in challenging settings. You will commonly find them in marine engineering components like propeller shafts and pump impellers, where saltwater is a constant threat. They are equally vital in the oil and gas industry for valve stems and fasteners, and in chemical processing equipment handling corrosive substances. Essentially, these forgings are the go-to choice for any application demanding reliability under a combination of mechanical stress and harsh, corrosive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
