Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a reputation as a trusted name in the supply of high-performance alloys. We take pride in our meticulous approach to providing top-tier materials, with a special focus on the exceptional quality of our Inconel 686 bars and rods. Our commitment is to partner with industries that demand nothing less than complete reliability, ensuring that every piece we supply meets the toughest standards of performance and durability in challenging environments.
The standout performance of Inconel 686 stems from its carefully balanced composition. It is a nickel-chromium-molybdenum alloy fortified with tungsten, which gives it an outstanding defense against a wide range of corrosive chemicals. This mix of elements ensures the material retains formidable strength and toughness, even when exposed to high temperatures. This unique combination makes the bars and rods incredibly durable in harsh conditions where other materials would quickly degrade.
| Element | Content (%) |
|---|---|
| Nickel, Ni | 59 |
| Chromium, Cr | 19-23 |
| Molybdenum, Mo | 15-17 |
| Iron, Fe | ≤ 5 |
| Tungsten, W | 3.0-4.40 |
| Manganese, Mn | ≤ 0.75 |
| Phosphorous, P | ≤ 0.040 |
| Sulfur, S | ≤ 0.020 |
| Titanium, Ti | 0.020-0.25 |
| Carbon, C | ≤ 0.010 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@21-100°C/69.8-212°F) | 11.97 µm/m°C | 6.650 µin/in°F |
Yes, Inconel 686 Bars/Rods are designed to perform exceptionally well in high-temperature environments up to 980°C.
Yes, Inconel 686 bars/rods are weldable using standard techniques, but preheating and specialized filler materials are recommended to ensure strong, corrosion-resistant welds.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@nimishmetal.com
The robust nature of these bars and rods makes them the ideal choice for some of the most demanding industrial sectors. They are essential components in chemical processing plants, handling aggressive acids, and in pollution control systems like flue gas desulfurization units. You’ll also find them in marine environments and on offshore platforms, where resistance to pitting and crevice corrosion is non-negotiable for long-term reliability and safety in critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nimish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Safat, Kuwait
