Aluminium 2017 Forgings

Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a reputation as a trusted name for precision-engineered components. We take particular pride in our expertise with Aluminium 2017 Forgings, a material chosen by engineers who demand exceptional strength and machinability. Our approach is hands-on, ensuring that every forged part we supply is meticulously crafted to meet the demanding specifications of various industries, providing reliable solutions that form the backbone of critical machinery and structures.

Aluminum 2017 Press Forging Manufacturer in Hawalli, Aluminium 2017 Compression Forging Al Ahmadi, Aluminium Alloy 2017 Impression Die Forging Size Chart, Aluminum Alloy UNS A92017 Upset Forging Dealer in Al Ahmadi, Al 2017 Open Die Forging Price in Kuwait, Stockist of Aluminum 2017 in Jahra, Aluminium Alloy Closed Die Forging Price List in Safat, Aluminum Alloy UNS A92017Open Die Forging Weight Chart, DIN 3.1325 Aluminium 2017 Closed Die Forging Exporter in Hawalli, Al 2017 Closed Die Hammer Forging Supplier in Kuwait

Aluminium 2017 Cold Forging

Aluminium 2017 Hot Forging

Aluminium 2017 Rolled Forging

What is Aluminium 2017 Forgings?

Aluminium 2017 is a durable alloy primarily composed of copper, which gives it impressive strength. It’s known for its excellent machining characteristics, allowing for the creation of complex and intricate parts with smooth finishes. After undergoing a heat-treatment process, it achieves even greater mechanical properties, making it significantly stronger than many other aluminium alloys in the 1000, 3000, and 5000 series, which is why it’s often selected for high-stress applications.

Aluminium 2017 Open Die Hammer Forging Stockist in Safat, Aluminum 2017 Impression Die Forging Distributor in Kuwait, Aluminium 2017 Cold Forging Stockist Salmiya, 2017 Aluminium Alloy Open Die Forging Exporter in Kuwait, Aluminum Alloy 2017 Compression Forging Price in Salmiya, 2017 Al Upset Forging Dimensions Jahra, Aluminium 2017 Forgings Supplier in Kuwait, Al 2017 Open Die Hammer Forging Supplier in Jahra, UNS A92017 Aluminium Alloy Press Forgings in Hawalli

Aluminium 2017 Forgings Specifications

Standards : ASTM B247, B247

Temper : T6 T651 T6511

Specification : DIN, ASTM, BS and all International Standards

Flat bar blocks : up to 27″ width and 15,000 lbs.

Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length

Discs and hubs : up to 50″ diameter and 20,000 lbs.

Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length

Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.

Aluminium 2017 Forgings Chemical Compositions

Grade	Al	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others Each	Other Total
2017	Rem	0.20-0.8	0.7 max	3.5-4.5	0.40-1.0	0.40-0.8	0.10 max	0.25 max	0.15 max	0.05 max	0.15 max

You Need Our Support, to Have Any Projects?

Test Certificate

Why Nimish Metals?

Packaging

Aluminium 2017 Forgings Mechanical Properties

Material	Condition	Tensile Strength (N/mm²) min		Yield Strength		Elongation in 4D %
		ksi	Mpa	ksi	Mpa
2017	2017-T4 Bar	55	379	32	221	12

Aluminium 2017 Equivalent Grades

European Standard	OLD	WNr	UNS	ISO	USA (AA)	GERMANY (DIN)
AW-AlCu4MgSi	AU4G	3.1325	A92017	AlCu4MgSi	2017	AlCuMg1

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Aluminium 2017 Forgings Types

Aluminium Alloy 2017 Hot Forging Exporter in Al Ahmadi, Aluminium 2017 Forgings Manufacturer in Salmiya, Aluminium Alloy 2017 Forgings Industrial Forgings Distributor Exporter in Kuwait, DIN 3.1325 Aluminum Alloy 2017 Seamless Rolled Forging Supplier in Jahra, Al 2017 Forgings Cold Forging Size Chart in Safat, Aluminium 2017 Compression Forging Size Chart in Kuwait, UNS A92017 Aluminium Open Die Forging Stockist in Jahra, ASTM B221 Al Forging Price List Hawalli, Aluminum 2017 Press Forging Supplier in Kuwait

Frequently Asked Questions (FAQ)

Can Aluminum 2017 be used for high-temperature forging applications?

Aluminum 2017 is suitable for forging but has limited high-temperature resistance. For high-temperature forging applications, consider alloys with better heat resistance, like 2219 or 2618.

How does the workability of Aluminum 2017 affect the forging process?

The workability of Aluminum 2017, being moderate, affects forging by requiring precise temperature control (400–480°C) to prevent cracking and achieve proper plastic deformation, making it suitable for intricate shapes with care.

What are the advantages of using Aluminum 2017 for custom forgings?

Aluminum 2017 offers high strength, excellent machinability, good corrosion resistance, and ease of welding, making it ideal for custom forgings in aerospace, military, and high-performance applications.

Aluminium 2017 Forgings Uses

The robust nature of Aluminium 2017 Forgings makes them perfect for demanding roles. You’ll commonly find them in critical aerospace components like aircraft structures and parts. They are also essential in the automotive industry for high-stress components like hydraulic pistons and parts requiring superior wear resistance. Beyond these, they are widely used in heavy-duty machinery, precision instruments, and anywhere a lightweight yet incredibly strong forging is needed for long-term reliability.
