Nestled in the industrial heart of Safat, Kuwait, Nimish Metal has built a strong reputation as a trusted manufacturer and supplier of precision-engineered components. We take particular pride in our expertise with Aluminium 2014 Forgings, a high-strength alloy we expertly shape to meet the most demanding specifications. Our team understands that durability and reliability are non-negotiable, which is why we focus on delivering forged solutions that provide exceptional performance and structural integrity for a wide range of industrial applications.
The standout quality of Aluminium 2014 lies in its specific composition, which features a significant copper content alongside manganese and magnesium. This blend is precisely what gives it such impressive mechanical properties. Once forged, this alloy achieves exceptional strength, hardness, and impressive resistance to wear and tear. While it may not be the first choice for highly corrosive environments, its remarkable toughness makes it a go-to material for situations where the primary requirement is sheer structural strength and the ability to withstand heavy loads.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| Aluminium 2014 | A92014 | 3.1255 | EN AW-2014 | HE15 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
Yes, Aluminum 2014 is suitable for high-temperature forging applications due to its excellent strength, thermal resistance, and good machinability, making it ideal for aerospace and automotive components.
Aluminum 2014 offers high strength, excellent machinability, good wear resistance, and superior performance under high-stress conditions, making it ideal for aerospace, automotive, and structural custom forgings.
The robust nature of Aluminium 2014 Forgings makes them indispensable in industries where failure is not an option. You’ll commonly find these components forming the backbone of aerospace structures, in critical aircraft parts, and within heavy-duty automotive and transportation systems. They are also essential in the construction of high-stress machinery, military hardware, and even in the fabrication of durable climbing equipment. Essentially, any application that demands a perfect balance of lightweight aluminium with the unwavering strength of forged metal is an ideal fit for this remarkable alloy.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
